AdamChandler's "Rosie Red" 2018 GS Adventure Build Thread

Discussion in 'GS Boxers' started by AdamChandler, Oct 4, 2018.

  1. Dackrover

    Dackrover Been here awhile

    Joined:
    May 17, 2018
    Oddometer:
    365
    Location:
    New York
    Did you screw #3 into the location for #4...and are now in the process of trying to get #4 into the #3 location?
  2. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    No mis-matched bolts. I am screwing in the correct bolt into the correct hole. It's just not going in perfectly straight.
  3. The Cone of Silence

    The Cone of Silence Been here awhile

    Joined:
    Jan 16, 2006
    Oddometer:
    251
    Location:
    Kurrajong, New South Wales, Australia
    Just out of curiosity, if it is a threadlocker issue, I wonder if warming up the bolt might help to clean the track?
    AdamChandler and Boondox like this.
  4. Dackrover

    Dackrover Been here awhile

    Joined:
    May 17, 2018
    Oddometer:
    365
    Location:
    New York
    If the above statement as to bolt type were true...you'd be trying to place a bolt that is listed as part #4 into hole #3. I guess you just were in error then, and are indeed working on a M12x1.5 at hole 3?

    Eta: Placing a coarse thread into a finely threaded hole could behave as you describe, whereas you probably could have more easily mis-screwed a fine-threaded bolt into a coarsely threaded hole at 4 -- assuming overall length was compatible with said mismatch. You might want to check again, imo?!?!?
    regnaDkciN and FarmerKeith like this.
  5. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    I did put a heat gun to it. No change. I think a thread-chaser is needed as these threads on the frame are full of thread-locker gunk. A proper chase will clean up the thread and make this much easier. I just want to make sure I get the right one.
  6. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    Shit, dackrover was right. Don't drink a bottle of Sauvignon Blanc and work on your bike.
    sgazzetti and Huckwheat like this.
  7. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA




    Since I'm behind on actually editing videos of the bike modifications, I did a quick one-take video update.


    Edit: Hit a mile-stone:
    [​IMG]
  8. Dan-M

    Dan-M Long timer Supporter

    Joined:
    Aug 21, 2007
    Oddometer:
    3,051
    Location:
    US 550 & I-25
    Did you put #4 in first? If you did, it may be easier to get #3 started without the bottom attached.
    AdamChandler likes this.
  9. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    On my last bike, I actually put the bottom bolt in first, then I jacked up the bike from the skid plate until the top bolt aligned (compressing the rear swing arm) and it lines up perfectly. I was just test fitting both bolts (glad I did) to clear any left over thread locker.
  10. Dackrover

    Dackrover Been here awhile

    Joined:
    May 17, 2018
    Oddometer:
    365
    Location:
    New York
    He just needed to put the correct bolt into the correct hole. Just glad he didn't take that full-on tap he linked from Amazon to the hole, before at least checking whether I had diagnosed his error accurately. Boring out his frame would have been a real mistake! Never fear being unsure...cower instead before absolute certainty!
  11. Dackrover

    Dackrover Been here awhile

    Joined:
    May 17, 2018
    Oddometer:
    365
    Location:
    New York
    I figured that's what you had done. You're welcome.
  12. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    Always assume I’ve been drinking.
  13. Dackrover

    Dackrover Been here awhile

    Joined:
    May 17, 2018
    Oddometer:
    365
    Location:
    New York
    Sir...let go of the innocent GS and back away from it slowly...keep your hands where I can see them....
    AdamChandler likes this.
  14. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    Too late. Tonight I’m doing wiring.
  15. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    Just a few terrible iPad photos mixed in with some decent photos to show where things are.

    In Progress:
    • Wiring for Denali Soundbomb at 90% (not electrified)
    • Wiring for Clearwater at 85% (not electrified)
    • Wiring for Sargent Seat 0% (staged)
    • PDM60..staged, not hooked up
    • Touratech Shocks 90% (oil reservoir not hooked up)
    • Billie Brake Light - 90% (needs to be connected to CanOpener)
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]


    Completed:
    • Yacugar Steering Damper
    • Touratech Steering Stop
    • Touratech Adventure Mirrors
    • SW-Motech Mirror Extensions
    • grip puppies
    • Rox Risers
    • ZTechnik Windscreen stabilizer

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]


    Wiring? You be the judge:
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
  16. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    Time to go watch videos on how to install PDM60.
    [​IMG]
  17. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    A few videos are recently uploaded. I have yet to add titles, tags or descriptions (going to work on that now): EDIT DONE updating titles.



    (language / rant. sorry)
    deadflagblues and GrusMC like this.
  18. nostatic

    nostatic i drank what?!? - Socrates Supporter

    Joined:
    Jun 5, 2008
    Oddometer:
    2,388
    Location:
    Lost Angeles
    Next time you might want to add some photos to make it easier to understand :D

    I guess you don't need a wire clothes hanger to snake the wiring through the nooks and crannies...
  19. wrussell61

    wrussell61 Card Carrying Cult Member

    Joined:
    Jul 3, 2014
    Oddometer:
    119
    Location:
    Texas (or Tejas)
    Adam - do yourself a favor and get a pair of flush cuts - https://www.amazon.com/Cutter-Light...d=1543410952&sr=8-8&keywords=flush+cut+pliers - or similar. You can find them in any big-box or hardware store as well. I think most of mine have been X-Celite (sp?) brand but any one will do. The idea is to cut the zip tie absolutely flush with the head. You should be able to run your finger over it and not feel it.

    You have about 150 zip ties in the photos above and almost all of them have a little sharp dagger sticking out of the head where you have cut them with diagonal cutters. Those are just waiting to scratch or cut you when you are wrenching on the bike.

    Looking good though. Carry on.
  20. AdamChandler

    AdamChandler Ascending n00b Supporter

    Joined:
    Feb 29, 2016
    Oddometer:
    5,685
    Location:
    Hanover, NH USA
    Good tip. Grabbed one. I'm using electrical snips. not too flush and I've cut my finger on zip ties a few times putting my hand in tight spots.

    I'm looking for a bit of help with wiring. Let me throw together a diagram and maybe it'll help.
