Call all XR600R!!!

Discussion in 'Thumpers' started by CSMonte, Dec 8, 2008.

  1. 2manyrides

    2manyrides shifty charactor

    Joined:
    Aug 17, 2008
    Oddometer:
    2,566
    Location:
    Citrus Heights Ca.
    So you’ve gone “hightech”?
  2. bork

    bork Been here awhile

    Joined:
    Oct 30, 2013
    Oddometer:
    615
    I use solid copper 14 ga insulated house wire.
    rustyx likes this.
  3. 2manyrides

    2manyrides shifty charactor

    Joined:
    Aug 17, 2008
    Oddometer:
    2,566
    Location:
    Citrus Heights Ca.
    So, Another high tech solution... Strap it down any way you can and don't worry about the dampening that a bit of stretchy rubber provides.
    Tell that to a 5.8 gallon tank... Don't worry about it...
  4. JAB

    JAB Unsprung Weight Supporter

    Joined:
    Dec 2, 2004
    Oddometer:
    1,692
    Location:
    Beautiful Monrovia
    How about cutting out the rubber and using nylon webbing on the factory rings. Will damp a little and the bit of stock cable will give the strength it needs. Make the webbing just a bit short and stretch it into place.
  5. 2manyrides

    2manyrides shifty charactor

    Joined:
    Aug 17, 2008
    Oddometer:
    2,566
    Location:
    Citrus Heights Ca.
    JAB, those are the considerations passing through my mind. How to make, alter, or rebuild one.
    Of course the cable part of it is an overly long safety harness should the rubber break and you are doing a flip in the air. It’s way too long to rely on to keep things in place.

    Some day I will get something fabricated. Just looking to what/if anyone has a good start on that. Keep the ideas coming...

    I keep a couple new straps in the parts bin, but am tired of breaking them on one 600 or another. Besides, they aint cheap!

    The temporary fix I put on my friend’s 95 seems to be holding up and I’ve already had it on and off a few times.



    I put a fix on it because the last time I mentioned having spares to a buddy, it was like... wow, thanks... see ya...time to order more. Like I said in original post... sick of it.
  6. Karabanov

    Karabanov n00b

    Joined:
    Feb 29, 2020
    Oddometer:
    4
    Location:
    Russia
    I already had a double ring and a ribbon of cloth. Holds well and does not weaken. Most helmets have this mounting system. I didn't know Honda was planning rubber there :hmmmmm

    Attached Files:

    2manyrides and JAB like this.
  7. JAB

    JAB Unsprung Weight Supporter

    Joined:
    Dec 2, 2004
    Oddometer:
    1,692
    Location:
    Beautiful Monrovia
    [​IMG]

    This is perfect.
  8. ossaboy2867

    ossaboy2867 Been here awhile

    Joined:
    Dec 5, 2014
    Oddometer:
    135
    Location:
    Wellsville
    Finally got the frame and hubs back from powder coating, time to start re lacing the wheels
    1A2F0DC5-0960-41CF-954D-5DAEECB298F3.jpeg 6922F473-9E07-4A7E-BEB4-CC9D5E6CD53E.jpeg 4FEA7410-A2F3-46F1-A8A7-5876CA3F4EEB.jpeg AFD76EC1-72D3-487C-8BAF-E5F6EDFC1B7A.jpeg FA87BF40-6C56-406D-9ED0-D68A2375239F.jpeg
  9. ossaboy2867

    ossaboy2867 Been here awhile

    Joined:
    Dec 5, 2014
    Oddometer:
    135
    Location:
    Wellsville
  10. thebigman

    thebigman XR's all the way . Big Thumps or V-twins

    Joined:
    Jul 9, 2010
    Oddometer:
    4,211
    Location:
    Texas Gulf Coast
    Can ya elaborate to the peanut gallery how you come up with the correct offset of the hub , did you take a measurement before
    you tore it down or does the manual talk about this ? How bout if you were using a diff width hoop , how would you decipher
    offset ? Thanks
  11. mcma111

    mcma111 Long timer

    Joined:
    Jul 17, 2007
    Oddometer:
    17,783
    Location:
    San Francisco,Ca.
  12. thebigman

    thebigman XR's all the way . Big Thumps or V-twins

    Joined:
    Jul 9, 2010
    Oddometer:
    4,211
    Location:
    Texas Gulf Coast
  13. ossaboy2867

    ossaboy2867 Been here awhile

    Joined:
    Dec 5, 2014
    Oddometer:
    135
    Location:
    Wellsville
    Sure. As mcma111 noted the offset dimension is listed. But....lets say you have no idea what it should be.

    As you can see I have the swingarm mounted to my mill, but you could use a sturdy table or bench. I measured where centerline of the swing arm is and marked center using tape streched taught across the two arms. Basically I have tape across the two sides filling in the void where the wheel would be, and a line representing center drawn down the middle.

    Leave enough room to install the bare hub with all the spacers and fixings included. You can see I have the center of the hub wrapped in tape with a line on it.

    Centerline determined on the swingarm/tape is now transfered on the the hub where you have tape wound on the center (you can still see this in my photos).

    You now have a centerline on the hub to work from if needed. Remove the tape when your done!

    I hope this helps, I didn’t take pictures of all the setups.

    thebigman likes this.
  14. ossaboy2867

    ossaboy2867 Been here awhile

    Joined:
    Dec 5, 2014
    Oddometer:
    135
    Location:
    Wellsville
    F7732F56-173B-438B-8DE0-0295898CAD75.jpeg 5D226593-3E12-49C2-AFD1-225D6AF6F070.jpeg F29BF834-B6F9-4B61-B7D6-5EDB260F3572.jpeg E04FCA81-A629-4703-843C-F7789BAA6100.jpeg
    thebigman likes this.
  15. ossaboy2867

    ossaboy2867 Been here awhile

    Joined:
    Dec 5, 2014
    Oddometer:
    135
    Location:
    Wellsville
  16. ossaboy2867

    ossaboy2867 Been here awhile

    Joined:
    Dec 5, 2014
    Oddometer:
    135
    Location:
    Wellsville
    4DE9E40E-1653-4341-B156-882BFF0890B0.jpeg Here is the front rim offset measure.
    thebigman likes this.
  17. ossaboy2867

    ossaboy2867 Been here awhile

    Joined:
    Dec 5, 2014
    Oddometer:
    135
    Location:
    Wellsville
    Made some progress today
  18. cmbthumper

    cmbthumper Been here awhile Supporter

    Joined:
    Sep 29, 2018
    Oddometer:
    829
    Location:
    Ramona, CA
    I needed a CA Plated bike so picked this up today. Had a 97' XR600 and brought back a sh*t ton of memories. PO was at Sea Level so will re-jet and clean carb.

    20200717_110213.jpg 20200717_133758.jpg 20200717_133818.jpg 00L0L_2LC2vCoIxJF_0t20lM_1200x900.jpg
  19. spezjag

    spezjag Long timer Super Supporter

    Joined:
    Dec 29, 2004
    Oddometer:
    17,160
    Location:
    Northern Virginia, USA
    ^ Congratulations - that's a fine looking bike!
    cmbthumper likes this.
  20. cmbthumper

    cmbthumper Been here awhile Supporter

    Joined:
    Sep 29, 2018
    Oddometer:
    829
    Location:
    Ramona, CA
    Thank you for that. Look forward to re-learning about the XR600, what parts mix with other bikes etc etc.

    My other ride i just finished.
